An
opto-isolator also called an
opto-coupler or photo-coupler allows a signal to pass from one circuit to another but allows the two circuits to remain electrically isolated. The most common
opto-isolator which comes in
IC package consists of an LED which shines onto the base of a photo-transistor (usually an
npn transistor) and allows current to flow from collector to emitter until the LED is turned off. When a signal is applied to the LED it then shines light that is varied in brightness with the same amplitude as the input signal, this light lands upon the photo-transistor (the resistance of the collector/emitter junction now changes with the varying light) which passes the signal onto the next circuit.
Basic opto-isolator symbol.
If you do a lot of work on switch mode power supplies than you have surely seen the
opto-isolators used in the feed back section of the power supply.
Opto-isolators in LCD TV SMPS.
If you want to read more about
opto-isolators including my 3 methods for testing them than
download my free article "
Understanding and Testing Opto-isolators" by
clicking here.
Included in the article is a schematic and parts list for a simple
opto-isolator tester.
Don't forget to visit
www.preherservices.com and also if you have any electronics related questions you can email me
john@preher-tech.com for assistance.
