Thursday, February 18, 2010

Samsung LNT4065FX/XAA, Repaired

Went on a service call to a customers home with a Samsung LNT4065FX/XAA that was slow to power on and often would get pinkish/violet pixels and artifacts in the picture. Upon opening the back of the TV I immediately noticed two puffed and vented electrolytic capacitors on the SMPS board. I checked all the electrolytic capacitors on the SMPS board with my ESR/capacitance meter but only the two puffed and vented capacitors were bad. After replacing the electrolytic capacitors, both 2200uF @10V, locations CM852 and CM853 and reassembling the TV it turned on and worked perfectly.




Friday, February 12, 2010

Samsung Syncmaster 906BW, LS19MEWSFY/XAA, Repaired

Samsung Syncmaster 906BW, LS19MEWSFY/XAA LCD monitor came into the shop today with no picture(really it was that the back lights were not lighting). Upon opening the monitor and removing the SMPS/Inverter PCB, I noticed 2 puffed and vented electrolytic capacitors right away. I checked all the rest of the electrolytic capacitors in the SMPS with my ESR meter to make sure no others were bad and they all were within tolerance for both ESR and capacitance. I scanned the SMPS for bad solder connections and found none. Next I removed the 2 1000uF @10V electrolytic capacitors that were puffed at locations C109 and C110 and replaced them with 2 1000uF @25V electrolytic capacitors with a 125 degree Celsius temperature rating(not necessary to go up in temp. and voltage rating this much or at all but don't use anything less than the originals). After reassembling the monitor and turning the monitor on, it worked like new.










You may also be interested in our LCD TV Repair Guide. Click here to read more.



Friday, February 5, 2010

SMPS Info Page

Here is a cool PDF that has lot's of free information to help you understand the basic and most common SMPS topologies.



Click here to visit the website and start reading about SMPS.




Another Sceptre X32GV-Komodo, Repaired

Sceptre X32GV-Komodo

Symptom:

TV will play fine for maybe a day or two and then turning on one time it will display video poorly, picture has artifacts, a couple flickering areas of pixels and intermittent horizontal line/lines for a couple minutes to a half hour then TV will turn off with no standby/power light and can not be turned on until unplugging and the plugging back in. TV may work again for a day or two before it repeats the failure.

Repair:

Replaced bad electrolytic capacitors, 1uF(didn't record voltage), 470uF 10V and 220uF 35V on SMPS board. Locations C202, CS124, CS118 and CS206.


Check out LCD TV Case Histories and find a quick fix for your broken LCD TV.

Tuesday, February 2, 2010

Polaroid, FLM-1911, Repaired.

This one comes from Dave's TV in grants pass OR.

Symptom:

White screen and a few faint vertical lines on picture.

Repair:

Replaced bad electrolytic capacitors, 470uF @25V. Locations C806, C807, and C808 on the SMPS board.

Thanks for the great tip Dave. Get more great tips from Dave by clicking on the link below.

Dave's TV Youtube Page

Also check out LCD TV Repair Case Studies, for many more LCD TV quick fixes.

Sceptre X32GV-Komodo, Repaired

Enjoy another repair from Preher-Tech.


X32GV-Komodo-

Symptom:

No power, sometimes standby/power LED will blink red.

Repair:

Replaced bad electrolytic capacitors, 470uF 10V and 220uF 35V on SMPS board. Locations CS118 and CS206.

Check out LCD TV Repair Case Histories.

LG RM-32LZ50, Repaired

Another repair from Preher-Tech

LG RM-32LZ50

Symptom:

No picture but has sound sound.

Repair:

Remove R60 SMD resistor on
Inverter PCB.

Check out LCD TV Repair Case Histories.

LG RM-30LZ50, Repaired

LG RM-30LZ50-

Symptom:

Irregular glittering speckles on screen.

Repair:

Remove C857, 220uF @16V electrolytic capacitor on main board
and replace with 470UF @16V electrolytic Capacitor.


Check out LCD TV Repair Case Histories.

Monday, February 1, 2010

LCD TV Repair Case Histories

Our newest ebook release. This is a straight to the point guide, "LCD TV Repair Case Histories". Common LCD TV makes and models, symptoms of failure and what was done to repair the TV. Learn what is needed to fix your broken LCD TV and get email support from a professional. This 33 page guide is only $10 and you can download it immediately after purchasing.
